DP/ASi Link to S7
Destination area of The destination area of data record 140 is located in data block DB 59, for
DR140 example. The following table describes the contents of DB59:
Address Name
0.0
+0.0 Vorh_Slaves
*1.0
+4.0 Akt_Slaves
*1.0
+8.0 Proj_Slaves
*1.0
+12.0 Konf_Flag
+12.1 Nullslave
+12.2 AutoProg_Frei
+12.3 AutoProg_Moegl
+12.4 Nrmbetr_akt
+12.5 Offl_akt
+12.6 Spgvers_flt
+13.0 Version_1
+14.0 Version_2
+15.0 Version_3
+16.0 Datum_1
+17.0 Datum_2
+18.0 Datum_3
+19.0 Datum_4
+20.0 Datum_5
+21.0 Datum_6
=22.0
6-8
Type Initial Value
STRUCT
ARRAY[0..3]
BYTE
ARRAY[0..3]
BYTE
ARRAY[0..3]
BYTE
BOOL FALSE
BOOL FALSE
BOOL FALSE
BOOL FALSE
BOOL FALSE
BOOL FALSE
BOOL FALSE
BYTE B#16#0
BYTE B#16#0
BYTE B#16#0
BYTE B#16#0
BYTE B#16#0
BYTE B#16#0
BYTE B#16#0
BYTE B#16#0
BYTE B#16#0
END_STRUCT
Comment
Slaves present
Slaves enabled
Slaves configured
Config_OK flag
Null slave present
Automatic programming enabled
Automatic programming possible
Normal mode enabled
Offline mode enabled
ASi power supply missing
Version_Part 1
Version_Part 2
Version_Part 3
Date_Part 1
Date_Part 2
Date_Part 3
Date_Part 4
Date_Part 5
Date_Part 6
