DP/ASi Link to S7
Data record 141 Data record 141 reads outs the parameter echoes of the different ASi slaves.
You can evaluate the reactions of the different ASi slaves in a parameter echo
following a "WR_REC" write job in the user program. You thus obtain a cur-
rent image of the state of the ASi slaves. A nibble is assigned to every ASi
slave.
Table 6-4
6-4

Structure of data record 141: Read parameter echoes of ASi slaves

Byte Parameter Echoes of ASi Slaves (4 Bits in All Cases)
Bits 4 to 7
0 –––––
1 Slave 2
2 Slave 4
3 Slave 6
4 Slave 8
5 Slave 10
6 Slave 12
7 Slave 14
8 Slave 16
9 Slave 18
10 Slave 20
11 Slave 22
12 Slave 24
13 Slave 26
14 Slave 28
15 Slave 30
Bits 0 to 3
Slave 1
Slave 3
Slave 5
Slave 7
Slave 9
Slave 11
Slave 13
Slave 15
Slave 17
Slave 19
Slave 21
Slave 23
Slave 25
Slave 27
Slave 29
Slave 31
