5.2

Example Using COM ET 200 Windows (Version 2.0 or Later)

Model structure
You wish to connect an ASi with an ASi slave over the DP/ASi link to the
PROFIBUS-DP. The ASi slave has the following assignment:
Assign the ASi slave to the ASi address as shown in Table 5-1.
Set the ASi address according to your requirements. The I/O code (refer to
Appendix B) results from the input/output assignment.
Table 5-1
1
Method
Proceed in the following order:
Confirming inputs
Confirm your inputs and write the data to the memory card. Insert the
memory card in your DP master. You can now commission the DP/ASi link.
Distributed I/O System DP/ASi Link
EWA 4NEB 710 6055-02b
one ASi slave with 4 inputs

Assigning the slave to the ASi address, an example

ASi Address Input/Output Assignment
4 inputs
Integrate the DP/ASi link into the PROFIBUS-DP (refer to section 5.1).
In the window, select Slave parameters Configure...
Double-click on the line containing ASi address 1 in the "I/O Code" field
to open a new input window.
Select the ASi slave with 4 inputs. Enter I/O code 0 in the field you se-
lected.
Position the mouse pointer in the field for the input address.
With base address, set this address for the address assignment of the
SIMATIC, for example, P54.
Select Auto addr. Start address P54.0 is assigned to the ASi slave.
Configuring the DP/ASi Link
I/O Code
0
5-5
