Installing and Wiring the DP/ASi Link
Resetting station
In certain cases the station number in the EEPROM of the DP/ASi link has to
numbers
be reset. Proceed in the following order:
1
2
3
4
5
6
4-14
Step
Turn off the power supply for the DP/ASi link.
Turn switch 8 on the DIP switch block to OFF.
Turn on the power supply for the DP/ASi link and then turn it off
after automatic start-up of the DP/ASi link. Start-up is aborted
with an error message. The station number is reset to 126.
Turn switch 8 on the DIP switch block to ON.
Turn on the power supply for the DP/ASi link.
Set the correct station number again with the ET 200 Handheld or
by means of the DP master.
Action
Distributed I/O System DP/ASi Link
EWA 4NEB 710 6055-02b
