Configuration Message
Example of
You have an DP/ASi link on which the ASi slave with the highest address to
determining length
which outputs are connected is slave 7; the ASi slave with the highest address
IDs
to which inputs are connected is slave 12.
Accordingly, the output area has a length of 4 bytes, for slave 7 is located in
the fourth byte. The length ID for the outputs is 03
The input area has a length of 6 bytes, for slave 12 is located in the sixth
byte. The length ID for the inputs is 05
D-8
H.
H.
Distributed I/O System DP/ASi Link
EWA 4NEB 710 6055-02b
