Installing and Wiring the DP/ASi Link
4.3 Commissioning
In this section
In this section you will learn what you have to take into consideration to
commission the DP/ASi link.
Sequence You commission the DP/ASi link in several steps.
Step
1 Install and wire the ASi completely. Connect
the ASi power supply to the ASi cable.
2 Install the DP/ASi link.
3 Select the station number you are using.
4 Connect the ASi cable to the DP/ASi link
M12 connector provided for it.
5 Connect the PROFIBUS-DP with a tee unit
to the DP/ASi link.
6 Connect the 24 V power supply for the DP/
ASi link to the remaining device connector.
7 Turn on the power supply.
Automatic start-up
After you have connected the DP/ASi link in the specified order and have
turned on the power supply of the DP/ASi link, the DP/ASi link starts up au-
tomatically (refer to section 7.1).
4-10
Action
Refer to the instructions for the different ASi
slaves and modules concerned to learn how
to install them.
The following assignment applies to the Sie-
mens ASi cable:
Refer to section 4.1
You can choose between EEPROM and DIP
switch block (refer to section 4.3.1).
EEPROM: refer to section 4.3.3
DIP switch block: refer to section 4.3.2
Refer to section 4.2
Refer to section 4.2
Refer to section 4.2
–
Note
ASi cable + = brown
ASi cable – = blue
