8.2.9
Diagnostics for a Default Start-Up with the IM308C
(6ES7 156 0AA00-0XA0 or Later, Issue 3)
Structure
For the default start-up, the diagnostic message contains 32 bytes of data and
complies with the PROFIBUS DP standard. The table below describes the
basic structure of the diagnostic message.
Table 8-19
0
1
2
3
4
5
6
7
8
9
10
11
12 to 15
16 to 31
Diagnostic data
Diagnostic bytes 12 to 15 indicate an ASi slave failure. Table 8-16 shows the
(bytes 12 to 15)
assignment of the ASi addresses.
Failed ASi slaves are marked "1".
Table 8-20
12
13
14
15
*
Distributed I/O System DP/ASi Link
EWA 4NEB 710 6055-02b
Basic structure of diagnostic message
Byte(s)
Contents
02
Station status 1
H
05
Station status 2
H
00
Station status 3
H
FF
Station number, DP Master
H
80
Manufacturer ID (801B
H
1B
H
1A
Header and length of module diagnosis
H
01
Module diagnosis
H
04
Header and length of first station diagnosis
H
00
Length of S7 area
H
22
Part 2 of diagnostic data
H
00
H
See Table
Part 1 of diagnostic data
8-20
See Table
Actual configuration of ASi installation
8-21
Indication of failed ASi slaves
Byte
Bit (Corresponds to ASi Address)
7
6
5
7
6
5
15
14
13
23
22
21
31
30
29
Byte 12.0 is not assigned.
Diagnostics and Error Handling
Meaning
)
H
4
3
2
1
4
3
2
1
12
11
10
9
20
19
18
17
28
27
26
25
0
*
8
16
24
8-21
