Technical Data
Dimension draw-
Fig. A-1 shows you the dimension drawing for the DP/ASi link.
ing
18
9
26
52
80
27
M23x1
57
Figure A-1 DP/ASi link; dimension drawing
Distributed I/O System DP/ASi Link
A-6
EWA 4NEB 710 6055-02b
