Installing and Wiring the DP/ASi Link
4.4.3

Programmer Connector (6ES5 762-2CA12)

Usage
A programmer connector is used to connect the programmer within the
IP 66/IP 67 environment to the PROFIBUS-DP.
Characteristics The programmer connector has the following characteristics:
Connections
A programmer connector has three bus connections:
4-18
Degree of protection: IP 66/IP 67 (refer to installation rules, section 4.1)
Can be operated at the following baud rates:
9.6; 19.2; 93.75; 187.5; 500; 1500; 3000; 6000 and 12000 kBd
The 3000, 6000 and 12000 kBd baud rates are possible only in the case of
operation with a suitable DP master – for example, the IM 308-C.
Can be located anywhere on the bus (exception: the programmer connec-
tor must not be located at the extremities of the bus cable, since the termi-
nating resistor must not be inserted).
Is not a bus station having a station number.
Is secured without opening the cover.
Connection for an "incoming" PROFIBUS-DP (possibly with power sup-
ply, 12-pin socket).
Connection for an "outgoing" PROFIBUS-DP (possibly with power sup-
ply, 12-pin socket).
Connection for adapter cable (refer to section 4.4.6) to the programmer
(12-pin socket)
Distributed I/O System DP/ASi Link
EWA 4NEB 710 6055-02b
