Diagnostics and Error Handling
Actual ASi confi-
Bytes 16 to 31 of the diagnostic message indicate the ASi configuration at
guration (bytes 16
the time of the parameterization message. An ASi slave is permanently assi-
to 31)
gned to every nibble. If an ASi slave is present in the configuration, its hexa-
decimal I/O code is entered at this point; missing ASi slaves are marked F
Table 8-21
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
Note
If you require a comparison between the setpoint and actual configurations,
you must do this in the user program.
8-22
Actual ASi configuration
Byte
Bits 7 to 4
Not applicable
I/O code for slave 2
I/O code for slave 4
I/O code for slave 6
I/O code for slave 8
I/O code for slave 10
I/O code for slave 12
I/O code for slave 14
I/O code for slave 16
I/O code for slave 18
I/O code for slave 20
I/O code for slave 22
I/O code for slave 24
I/O code for slave 26
I/O code for slave 28
I/O code for slave 30
H
Bits 3 to 0
I/O code for slave 1
I/O code for slave 3
I/O code for slave 5
I/O code for slave 7
I/O code for slave 9
I/O code for slave 11
I/O code for slave 13
I/O code for slave 15
I/O code for slave 17
I/O code for slave 19
I/O code for slave 21
I/O code for slave 23
I/O code for slave 25
I/O code for slave 27
I/O code for slave 29
I/O code for slave 31
Distributed I/O System DP/ASi Link
EWA 4NEB 710 6055-02b
.
