Configuration with Programmer Connector
Definition
If you wish to operate the programmer on the PROFIBUS-DP in an
IP 66/IP 67 environment, you require a programmer connector.
Connecting the
To connect the programmer to the programmer connector, you require two
programmer
plug-in connectors:
An ET 200 Handheld cannot be connected to the programmer connector. The
ET 200 Handheld can be plugged only into the bus connection of a slave sta-
tion (using the adapter cable).
Installation
Fig. 3-8 shows a possible installation for the configuration with a program-
mer connector.
External
power supply
PROFIBUS-DP
Figure 3-8
Distributed I/O System DP/ASi Link
EWA 4NEB 710 6055-02b
adapter cable
programmer connecting cable
PS
PS
PG
cntr.
Adapter cable
Programmer
connecting
cable
IP 20 world
Configuration with programmer connector
Configuration Options
IP 66/IP 67 world
DP/ASi link
DP/ASi link
DP/ASi link
3-9
