Programming

Commonly Used Acronyms
and Abbreviations
For convenience, a number of acronyms
and abbreviations are used throughout
this manual. These acronyms are
alphabetically listed and defined below.
Act = active
AH = Air Handler
Annunc = Annunciater
AS = Airside
Aux = auxiliary
BAS = building automation systems
ccfm = (100 cfm) cubic-feet-per-minute
Cfg = Configured, configuration
cfm = cubic-feet-per-minute
ckt = circuit
Cmd = command
Comp (s) = compressor, compressors
Cond = condenser, condensers
Config = configured, configuration
Ctrl = control
CV = constant volume
Cy = cycle
CW = clockwise
CCW = counterclockwise
Dflt = default
Diag = diagnostic
Dmpr = damper
DWU = Daytime Warmup
E/A = exhaust air
ECEM = exhaust control/enthalpy module
Econ = economizer, economizing
Ent = entering
Evap = evaporator
F/A = fresh air
Funct = function
GBAS = generic building automation
system (module)
Heat = Heat, heating
HEAT = where all caps HEAT (module)
HGBP = hot gas bypass
Hi = high
HI = where all caps Human Interface
HVAC = heating, ventilation and air
conditioning
ICS = Integrated Comfort System
IGV = inlet guide vanes
I/O = input/output
Indep = Independent
IOD = installation/owner/ diagnostic
manual
IPC = interprocessor communications
IPCB = interprocessor communications
bridge (module)
IWC = inches water column
LCD = liquid crystal display
General
Information
LH = left-hand
Lo = low
Manif = manifolded
Max = maximum
Min = minimum
Misc = miscellaneous
MCM = multiple compressor module
Mod = modulating
MWU = morning warmup
NSB = night setback panel
Num = number
O/A = outside air
Occ = occupied
Pos = position
Pot = potentiometer
PPM = parts per million
Press = pressure
Propor = proportional
psig = pounds-per-square-inch gauge
pressure
PWS = part-winding start
R/A = return air
Refrig = refrigerant
RHI = Remote Human Interface
RH = right-hand
rpm = revolutions-per-minute
RTM = RTM module
SA = supply air
SAP = supply air pressure
Sat = saturated
SCM = single compressor module
Setpt = setpoint
SF = supply fan
SRC = source
Stg = stage
Stnd = standard
STP = setpoint
Sw = switch
SZ = single-zone (unit airflow)
TCI = Tracer communications interface
module
Temp = temperature
UCM = unit control module
Unocc = unoccupied
VAV = variable air volume
VCM = ventilation control module
VDC = volts DC
Ventil = ventilation
VFD = variable frequency drive
VOM = ventilation override module
W/ = with
w.c. = water column
WU = warmup
