SETPOINT Menu

The SETPOINT menu allows you to
designate default zone temperature
setpoints, supply air and space pressure
setpoints, and low ambient compressor
lockout setpoints.
These setpoints are active (in use) for the
"Setpoint Source Selection" designated
as "DEFAULT" for these inputs.
When a setpoint screen displays for 30
minutes without a key being pressed, the
HI display will revert to the general
operating status screen. If this happens,
press the SETPOINT key again to return
to the setpoint menu.
Note: Some of the screens displayed in
this section may not be visible on your HI
since they are applicable only for particular
unit options.
Pressing the SETPOINT key will allow you
to view or modify unit setpoints.
To change setpoint values on a particular
screen:
1. Press the plus or minus key until the
correct value appears in the screen.
2. Press the ENTER key to confirm your
choice. If you've made an error, press
the CANCEL key to delete your entry.
To navigate to another screen:
1. Press the NEXT key to advance to the
next screen, OR
a. if no further changes are required and
you want to exit back to view the unit
operating status, press the STATUS key
once, OR
b. if you want to remain in the Setpoint
submenu, press the SETPOINT key
once and it will return you to the
beginning of that particular submenu,
OR
c. if you want to exit to another submenu
in the SETPOINT menu, press the
SETPOINT key twice. Then press the
NEXT key to scroll through the SET -
POINT submenu choices, OR
d. if you want to exit to another menu,
such as CONFIGURATION, press that
key once, then press the NEXT key to
scroll through those screens.
PKG-SVP01B-EN
Programming
SETPOINT Menu Screens
(Applicable for all units except as noted)
Default Supply Air Temp Setpoint(s)
Cooling: 55 F
Factory Presets: 55 F
Possible Values: 40-90 F
1. Pressing the NEXT key will display the following screen.
Default Supply Air Temp Setpoint(s)
Cooling: 67 F
Factory Presets: 100 F
Possible Values: Cool = 40-90 F
Heat = 40-180 F
1. Pressing the NEXT key will display the following screen.
Supply Air Temperature Deadband
Cooling: 8.0 F
Factory Presets: 8.0 F
Possible Values: Cool = 4-20 F
1. Pressing the NEXT key will display the following screen.
(On units with hydronic heat only)
Supply Air Temperature Deadband
Cooling: 8.0 F
Factory Presets: Cooling = 8.0 F
Heating = 4.0 F
Possible Values: Cooling= 4-20 F
Heating = 2-10 F
1. Pressing the NEXT key will display the following screen.
Default Daytime Warmup Setpoints
Initiate: 67 F
Factory Presets: Heat = 71 F
Cool = 74 F
Possible Values: Heat = 50-90 F
Cool = 52-92 F
1. Pressing the NEXT key will display the following screen.
SETPOINT
Heating: 71 F
Heating: 4.0 F
Terminate: 71 F
57
