STATUS Menu

The STATUS menu allows the user to
view various setpoints, operating
conditions (such as temperature and
humidity levels), and unit component
status (such as fan, compressor, heater,
and economizer operation).
STATUS screens in this section are
examples only. Pressing the + (Plus) key
while viewing any of the status display
screens will add that screen to the
CUSTOM menu. When a status screen
displays for 30 minutes without a key
being pressed, the LCD screen will revert
to the general operating status display. If
this happens, press the STATUS key
again to return to the status menu.
Following are sample status screens that
can be viewed by pressing the STATUS
key.
Note: Some of the screens in this section
may not be visible on your HI since they
are applicable only for particular unit
options.
Press the STATUS key to enter into the
status menu. The "STATUS MODE"will
automatically return to the power-up
screen after 30 minutes, if no keys are
pressed.
Note: The range for all temperature inputs
is –40 to 200 F . "ERR" will appear if the
temperature is out of range.
PKG-SVP01B-EN
Programming
STATUS Menu Screens
VAV OA FLOW
OCCUPIED
1. Pressing the NEXT key will display the following screen.
General System Status Submenu
Press ENTER to View Data in This Submenu
1. Pressing the NEXT key will bypass this section.
RTM Supply Fan Relay:
RTM Supply Airflow Proving:
Possible values: Fan = On, Off
Airflow = Flow, No Flow
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the previously displayed
screen.
3. Press the + (Plus) key while viewing any screen to add that screen to the custom
menu. Refer to the custom menu for the creation and maintenance of customized
menus.
4. Pressing the NEXT key will display the following screen.
(On units with IGV or VFD only)
IGV/VFD Cmd
Active Supply Air Pressure
Possible values: Increasing to 0-100%
Decreasing 100 to 0%
(On units without IGV or VFD only)
Active Supply Air Pressure
1. Pressing the NEXT key will display the following screen.
(On water-cooled units only)
WSM Water Pump Relay Status:
Active Water Flow Indication
Possible values: Pump Status = Off, On
Waterflow = Flow, No flow
1. Pressing the NEXT key will display the following screen.
STATUS
350.0 CCFM SUPPLY FAN ON
OA DMPR 0% DIAGNOSTICS
OFF
FLOW
30 %
2.0 IWC
2.0 IWC
OFF
Flow
