CONFIGURATION Menu

The self-contained unit has many
operating functions that are factory
preset. The following configuration
programming steps allow the user to
configure a replacement HI module for a
unit that is already in operation.
Refer to the unit model number on the
unit nameplate (on the control panel
door) while scrolling through the configu-
ration screens. Certain digits of this alpha/
numeric model number provide informa-
tion that must be entered at the HI for the
unit to operate properly.
Note: Some of the screens displayed in
this section are applicable only for particu-
lar options and are not visible unless those
options are installed on your unit.
Pressing the CONFIGURATION key will
allow you to view or modify unit set-
points.
To change setpoint values on a particular
screen:
1. Press the plus or minus key until the
correct value appears in the screen.
2. Press the ENTER key to confirm your
choice. If you've made an error, press
the CANCEL key to delete your entry.
To navigate to another screen:
1. Press the NEXT key to advance to the
next screen, OR
a. if no further changes are required and
you want to exit back to view the unit
operating status, press the STATUS key
once, OR
b. if you want to remain in the Setpoint
submenu, press the CONFIGURATION
key once and it will return you to the
beginning of that particular submenu,
OR
c. if you want to exit to another submenu
in the CONFIGURATION menu, press
the CONFIGURATION key twice. Then
press the NEXT key to scroll through
the CONFIGURATION submenu
choices, OR
d. if you want to exit to another menu,
such as SETPOINT key, press that key
once, then press the NEXT key to scroll
through those screens.
PKG-SVP01B-EN
Programming
Configuration - Model Num Digit 1
Unit Type
Possible Values: Commercial Self-Contained
1. Pressing the NEXT key will display the following screen.
Configuration - Model Num Digit 3
Condenser Medium
Possible Values: Water Cooled Condenser
Air Cooled Condenser
None - No Condenser
1. Pressing the NEXT key will display the following screen.
Configuration - Model Num Digit 4
Development Type
Possible Values: Signature Series
Modular Series
1. Pressing the NEXT key will display the following screen.
Configuration - Model Num Digit 5
Refrig Ckt Config
Possible Values: Independent
Manifolded
Note: Manifolded piping is only available on Signature Series units, 30 tons and larger.
1. Pressing the NEXT key will display the following screen.
Configuration - Model Num Digit 27
Water Economizer
Possible Values: Installed
Not Installed
1. Pressing the NEXT key will display the following screen.
(On all water-cooled units or units with a waterside economizer)
Configuration - Model Num Digit 29
Water Piping
Possible Values: Intermediate Piping
Basic Piping
None - No Piping
1. Pressing the NEXT key will display the following screen.
CONFIGURATION
Commercial Self-Contained
WATER COOLED CONDENSER
SIGNATURE SERIES
INDEPENDENT
INSTALLED
INTERMEDIATE PIPING
