Trane IntelliPak Signature Series Programming Manual page 26

26
Programming
Active Morning WU Temp Sensor Input From
RTM ZONE TEMP INPUT
Possible Values:
Sensor Range:
1. Pressing the NEXT key will display the following screen.
Active Zone Reset Sensor Input From
RTM ZONE TEMP INPUT
Possible Values:
Sensor Range:
1. Pressing the NEXT key will display the following screen.
Active OA Temperature Sensor Input From
RTM OUTSIDE AIR TEMP INPUT
Possible Values:
1. Pressing the NEXT key will display the following screen.
(On units with an airside economizer)
Active Outside Air Humidity Input From
OA HUMIDITY SENSOR INPUT
Possible Values: O/A Humidity Sensor Input
Sensor Range:
1. Pressing the NEXT key will display the following screen.
(On units with IGV, VFD, or with the SAP sensor enabled)
Active Supply Air Press Sensor Input From
RTM SA PRESSURE INPUT
Possible Values: RTM SA Pressure Input
1. Pressing the NEXT key will display the following screen.
STATUS
is
RTM Zone Temp Input
NSB Zone Sensor Setpoint Input
RTM Aux Temp Input
Heat Module Aux Temp Input
ECEM return Air Temp Input
®
ICS (Tracer Summit )
-40 to 200 F
is
RTM Zone Temp Input
NSB Zone Sensor Setpoint Input
RTM Aux Temp Input
Heat Module Aux Temp Input
ECEM Return Air Temp Input
ICS (Tracer Summit ® )
-40 to 200 F
is
RTM Outside Air Temp Input
ICS (Tracer Summit ® )
is
®
ICS (Tracer Summit )
0-100%
is 2.1 IWC
ICS (Tracer Summit ® )
82.0 F
82.0 F
86.0 F
30 %
PKG-SVP01B-EN
