PKG-SVP01B-EN
Programming
(On units with hydronic or electric heat)
Morning Warmup Function:
Morning Warmup Type:
Factory Presets: Function = Enabled
MWU Type = Full Capacity
Possible Values:
Function = Enabled, Disabled
MWU Type = Full Capacity, Cycling Capacity
1. Pressing the NEXT key will display the following screen.
(On units with hydronic heat)
Supply Air Tempering Function:
Warm Up Outside Air Used for Ventilation
Factory Presets: Function = Disabled
Possible Values:
Function = Enabled, Disabled
1. Pressing the NEXT key will display the following screen.
(On cooling-only units)
Unocc Mech Cooling Function:
Factory Presets: Function = Enabled
Possible Values:
Function = Enabled, Disabled
(On units with hydronic, electric, or external heat)
Unocc Mech Cooling Function:
Unocc Heating Function:
Factory Presets: Cooling and Heating Function = Enabled
Possible Values:
Cooling and Heating Function = Enabled, Disabled
1. Pressing the NEXT key will display the following screen.
(On units with a VCM)
OA Preheater Output Control :
Activate If Preheat Temp Below Setpoint
Factory Presets: Control = Enabled
Possible Values:
Control = Enabled, Disabled
1. Pressing the NEXT key will display the following screen.
Demand Limit Definition:
Cooling:
100 %
Factory Presets: None
Possible Values:
Cooling = None, 50%, or 100%
1. Pressing the NEXT key will display the following screen.
SETUP
ENABLED
FULL CAPACITY
DISABLED
ENABLED
OR
ENABLED
ENABLED
ENABLED
33
