System Map: Left View

Figure 1 - 5 - Left View
1. Security Lock Slot
2. Optical Device Drive Bay
(see page 2 - 3)
3. RJ-11 Modem Jack
4. S/PDIF-Out Jack
5. Microphone-In Jack
6. Headphone-Out Jack
7. Line-In Jack
CD Emergency Eject
If you need to manually eject a CD/DVD (e.g. due to an unex-
pected power interruption) you may push the end of a straight-
ened paper clip into the emergency eject hole. Do not use a
sharpened pencil or similar object that may break and become
lodged in the hole.
Media Warning
Don't try to remove a floppy disk/CD/DVD while the system is
accessing it. This may cause the system to "crash".
1
Go to the Control Panel and double-click Device
Manager (Hardware and Sound), then click the +
next to DVD/CD-ROM drives. Double-click on the
DVD-ROM device to bring up the Properties dia-
logue box, and select the DVD Region (tab) to bring
up the control panel to allow you to adjust the regional
code (see
DVD region detection is device dependent, not OS-
dependent. You can select your module's region
code 5 times. The fifth selection is permanent. This
cannot be altered even if you change your operating
system or you use the module in another computer.
Quick Start Guide
2
3
Changing DVD Regional Codes
"DVD Regional Codes" on page 2 -
System Map: Left View 1 - 13
1
4 5 6 7
5).
