Quick Start Guide
1

System Map: Left View

Figure 1 - 5
Left View
1. S/PDIF-Out Jack
2. Line-In Jack
(see page A -
3. Microphone-In Jack
4. Headphone-Out Jack
5. Optical Device Drive Bay
(for CD/DVD Device)
If you need to manually eject a CD/DVD (e.g. due to an unex-
pected power interruption) you may push the end of a straight-
ened paper clip into the emergency eject hole. Do not use a
sharpened pencil or similar object that may break and become
lodged in the hole.
Don't try to remove a floppy disk/CD/DVD while the system is
accessing it. This may cause the system to "crash".
1 - 10 System Map: Left View
1 2 3
3)
CD Emergency Eject
Media Warning
4
Changing DVD Regional Codes
Go to the Control Panel and double-click System >
Hardware (tab), click Device Manager, then click
the + next to DVD/CD-ROM drives. Double-click on
the DVD-ROM device to bring up the Properties di-
alogue box, and select the DVD Region (tab) to
bring up the control panel to allow you to adjust the
regional code (see
page 2 -
DVD region detection is device dependent, not OS-
dependent. You can select your module's region
code 5 times. The fifth selection is permanent. This
cannot be altered even if you change your operating
system or you use the module in another computer.
5
"DVD Regional Codes" on
5).
