System Map: Left View

2
1
3
The Mini-IEEE 1394 port only supports SELF POWERED IEEE 1394 devices. Make sure
you install the IEEE 1394 filter driver (see page
The card reader allows you to use the most popular digital storage card formats:
MMC (MultiMedia Card) / SD (Secure Digital) / MS (Memory Stick)
MS Pro (Memory Stick Pro) / MS Duo (requires PC adapter)
Mini SD (requires PC adapter) / RS MMC (requires PC adapter)
Note that the HDMI-Out Port supports video and audio signals to attached external dis-
plays (also see "HDMI Audio Configuration" on page B -
Install the Intel Matrix Storage driver to display the safe removal icon for e-SATA devices
in the taskbar (see "Intel® Matrix Driver Installation" on page 7 -
7
6
4 5
Mini-IEEE 1394 Port
4 - 6).
7-in-1 Card Reader
HDMI-Out Port
e-SATA Port
9
8
14).
42).
System Map: Left View 1 - 13
Quick Start Guide
Figure 1 - 7
Left View
1. HDMI-Out Port
2. e-SATA Port
3. Cable (CATV)
*
Antenna Jack
4. RJ-11 Phone Jack
5. RJ-45 LAN Jack
6. Mini-IEEE 1394
Port
7. ExpressCard Slot
(see page 2 - 7)
8. Optical Device
Drive Bay (for
DVD Device)
9. 7-in-1 Card
Reader
*Enabled with Optional
TV Tuner Only
See Appendix A for a more
detailed description of the
ports & jacks etc.
