Concise User's Guide

System Map: Left View

Figure 5
Left View
1. S/PDIF-Out Jack
2. Line-In Jack
3. Microphone-In Jack
4. Headphone-Out Jack
5. Optical Device Drive Bay
(for CD/DVD Device)
CD Emergency Eject
If you need to manually eject a CD/DVD (e.g. due to an unexpected
power interruption) you may push the end of a straightened paper clip
into the emergency eject hole. Do not use a sharpened pencil or sim-
ilar object that may break and become lodged in the hole. Don't try to
remove a CD/DVD/floppy disk while the system is accessing it as this
may cause the system to "crash".
Headphone Warning
Remove headphones from your ears when shutting the computer
down in order to prevent the higher level shutdown sound from caus-
ing hearing damage.
14 - System Map: Left View
1 2 3 4
5
Changing DVD Regional Codes
Go to the Control Panel and double-click System >
Hardware (tab), click Device Manager, then click the
+ next to DVD/CD-ROM drives. Double-click on the
DVD-ROM device to bring up the Properties dialog
box, and select the DVD Region (tab) to bring up the
control panel to allow you to adjust the regional code.
DVD region detection is device dependent, not OS-
dependent. You can select your module's region
code 5 times. The fifth selection is permanent. This
cannot be altered even if you change your operating
system or you use the module in another computer.
