System Map: Front & Rear Views
1
To prevent your computer from overheating make sure nothing blocks the vent(s)/fan intake(s)
while the computer is in use.
3
4
5
3
S-Video/Composite Cable
Overheating
6
3
The 7-pin S-Video Out Jack requires an adapter cable (7-pin S-Video plug
to 4-pin S-Video jack adapter) in order to connect to a standard S-Video ca-
ble (the y-cable pictured includes a yellow composite video jack).
HDTV Cable
1
2
7 8
9 10 11
7-Pin S-Video-Out Jack
System Map: Front & Rear Views 1 - 9
Quick Start Guide
Figure 1 - 4
Front & Rear Views
1. LCD Latches
2.
Consumer Infrared
*
Transceiver
3. 7-Pin S-Video-Out
Jack
4. DVI-Out Port
5. DC-In Jack
6. Vent/Fan Intake
7. RJ-11 Phone Jack
8. 2 * USB 2.0 Ports
9. Serial Port
*
10.
S-Video-In Jack
11. Security Lock Slot
*
Enabled with Optional Mini-
PCI TV Tuner Only
1
