Figure 1 - 6
Front & Rear Views
1. LCD Latches
2. Consumer
Infrared
Transceiver
*
3. Line-In Jack
4. S/PDIF-Out Jack
5. Microphone-In
Jack
6. Headphone-Out
Jack
7. Speakers
8. Vent/Fan Intake
9. DC-In Jack
10. DVI-Out Port
*Enabled with Optional
TV Tuner Only
See Appendix A for a more
detailed description of the
ports & jacks etc.
1 - 12 System Map: Front & Rear Views
System Map: Front & Rear Views
1
7
8
9
To prevent your computer from overheating make sure nothing blocks the vent(s)/fan in-
take(s) while the computer is in use.
