System Map: Front & Rear Views
1
3 4
Always completely discharge, then fully charge, a new battery before using it. Com-
pletely discharge and charge the battery at least once every 30 days or after about 20
partial discharges.
2
5
Battery Information
Quick Start Guide
Front & Rear Views
1. LED Indicators
2. LCD Latch
3. RJ-11 Phone Jack
4. RJ-45 LAN Jack
5. Battery
6. DC-In Jack
6
10 Cell Battery Warning
Please be careful when us-
ing the 10 cell battery.
The battery is heavy and ex-
tends beyond the case of the
computer. Moving the bat-
tery, or exposing it to shock
or vibration may interrupt the
battery contacts and cause
the computer to shutdown.
System Map: Front & Rear Views 1 - 9
Figure 1 - 4
