Quick Start Guide
1
System Map: Front & Rear Views
3
4
2
1 - 12 System Map: Front & Rear Views
5
Figure 1 - 4 - Front & Rear Views
The Mini-IEEE 1394 port only supports SELF POWERED IEEE 1394 devices.
1
1
6
Mini-IEEE 1394
1.
LED Indicators
2.
Serial Port
3.
Mini-IEEE 1394 Port
4.
1 * USB Port
5.
DC-In Jack
6.
Battery
