Introduction
Mainboard Overview - Top (Connectors)
Figure 9
Mainboard Top
Connectors
1. External Monitor
Port
2. RJ-45 LAN Jack
3. HDMI-Out Port
4. USB Ports
5. eSATA Port
7. Audio Board
8. Fingerprint and
TouchPad Cable
Connector
9. Keyboard Cable
Connector
10. Switch Board
Cable Connector
1 - 10 Mainboard Overview - Top (Connectors)
1
2
3
4
4
6
5
4
10
9
8
7
