Keyboard
Full-size "WinKey" keyboard (with numeric keypad)
Pointing Device
Built-in Touchpad (scrolling key functionality integrated)
Interface
Three USB 2.0 Ports and One USB 3.0 Port
Or Four USB 2.0 Ports*
*Note: it depends on your purchase configuration
One eSATA Port
One HDMI-Out Port
One Headphone-Out Jack
One Microphone-In Jack
One S/PDIF Out Jack
One RJ-45 LAN Jack
One External Monitor Port
One DC-in Jack
Card Reader
Embedded 9-in-1 Card Reader
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC/SDXC Compatible
MS (Memory Stick) / MS Pro / MS Duo
Dimensions & Weight
413mm (w) * 277.5mm (d) * 25.1 - 38.9mm (h)
3.1 kg with ODD & 48.84WH Battery
Environmental Spec
Temperature
°
°
Operating: 5
C - 35
C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Communication
Built-In Gigabit Ethernet LAN
(Factory Option) 1.3M Pixel USB PC Camera Module
(Factory Option) Bluetooth 2.1 + EDR Module
Wireless LAN Module Options:
(Factory Option) Intel® WiFi Link 6200 (802.11a/g/n) Wire-
less LAN Half Mini-Card Module
(Factory Option) Intel® WiFi Link 6300 (802.11a/g/n) Wire-
less LAN Half Mini-Card Module
(Factory Option) Third-Party 802.11b/g/n Wireless LAN
Half Mini-Card Module
Power
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19V, 4.74A (90W)
6 Cell Smart Lithium-Ion Battery Pack, 48.84WH
(Factory Option) Removable 6 Cell Smart Lithium-Ion Bat-
tery Pack, 62.16WH
Energy Star 5.0 Compliant
Introduction
Specifications 1 - 3
