Switcher Software, cont'd
6.
Figure 5-7 — Control program Audio Settings window
7.
Figure 5-8 — Control program IP Setting/Options window

Using the help program

For information on program features, press the F1 computer key; or click the
Help menu from within the ISS/ISM Control Program; or double-click the
ISS/ISM Help icon, shown at right, in the Extron Electronics group or folder.
For explanations of buttons or functions, click the tabs in the help screen to reach
the desired screen. Use a mouse or the Tab and Enter keys to select a button/
function. A description and tips on using the program appear on screen.

Button-Label Generator

You may wish to customize the labeling of the ISM's front panel buttons. Blank
templates for the ISM's button label windows are included in appendix B,
"Reference Information". However, you can easily create, customize, and print
labels for the switcher's input label window by using the Button-Label Generator
software. This program creates and prints labels that can be inserted into the input
label window on the switcher.
5-6 Integration Scaling Matrix Switcher • Switcher Software
If desired, on the task bar, click Tools > Audio Settings to set each input's
audio level or attenuation in the Audio Settings window (figure 5-7).
If desired, on the task bar, click Tools > IP Options to set the switcher's IP
parameters in the IP Settings/Options window (figure 5-8).
When the control program is connected to the switcher via the RS-232 link, the
Administrator and User password fields are not masked. If a password has
been inadvertently changed to an unknown value, you can look up and, if
desired, change a password in this window without knowing the current
password.
