Ethernet Operation, cont'd

Output resolution, rate, sync format, and polarity

The ISM 482 scales the input signal up or down to any of a number of output
resolutions and rates. The switcher outputs the scaled video as RGBHV or RGBS,
with user-selectable polarity, via either the program or preview connectors. The
table below shows the resolutions and rates available on the ISM 482.
Resolution 50 Hz
•
640 x 480
•
800 x 600
832 x 624
848 x 480
852 x 480
•
1024 x 768*
1280 x 768*
•
1280 x 1024*
1360 x 765*
•
1365 x 768*
1365 x 1024
1366 x 768*
•
1400 x 1050*
•
576p HDTV*
720p* HDTV @ 60 Hz only
1080p HDTV @ 60 Hz only
•
1080i HDTV
* Native DVI output resolution
✝ ✝ The output refresh rate is auto-selected, based on the video refresh rate of input 1.
6-10 Integration Scaling Matrix Switcher • Ethernet Operation
56 Hz 60 Hz 75 Hz
• •
• •
• •
•
•
• •
•
•
•
•
•
•
•
•
•
•
•
• For output resolutions with less than 1024 pixels horizontally, the
optional DVI output's true horizontal resolution is limited to 1024 pixels.
The vertical resolution is the selected vertical resolution. For these
resolutions, the ISM DVI output is 1024 x {selected vertical size}. For
example, if the output resolution is set to 640 x 480, the DVI output
card's actual resolution is 1024 × 480.
• For the 1365 x 1024, 1080p, and 1080i output resolutions, the optional
DVI output's true horizontal resolution is limited to 1280 pixels. For
these resolutions, the ISM DVI output is 1280 x {selected vertical size}.
For example, if the output resolution is set to 1080p, the DVI output
card's actual resolution is 1280 x 1080.
• The DVI card outputs all other selected resolutions normally.
• Resolutions marked with an asterisk (*) in the table above are native DVI
outputs, meaning that the DVI output fully supports the selected
horizontal and vertical resolution. The DVI output resolution for these
rates exactly matches the analog resolution.
✝
85 Hz Lock at 50/60 Hz
•
•
•
•
•
• •
•
•
•
•
•
•
•
•
•
•
•
Actual DVI output
1024 x 480
1024 x 600
1024 x 624
1024 x 480
1024 x 480
1024 x 768
1280 x 768
1280 x 1024
1360 x 765
1365 x 768
1280 x 1024
1366 x 768
1400 x 1050
720 x 576
1280 x 720
1280 x 1080
1280 x 540
