Cables and connectors

When using signals with a scanning frequency of 15-125 kHz and running
distances of 100 feet or more, use high resolution BNC cables to achieve
maximum performance.

Bulk cable

Extron Part
RG6/super high resolution cable
RG6 bulk , 500' (150m), single conductor
RG6-1 bulk , 1000' (300m), single conductor
RG6-5 bulk , 500' (150m), five conductor
MHR-5 Cable (Non-plenum)
MHR-5 bulk, 500' (150m)
MHR-5 bulk, 1000' (300m)
MHR-5p (Plenum) Cable
MHR-5P bulk, 500' (150m)
MHR-5P bulk, 1000' (300m)

Assorted connectors

BNC connectors
BNC male, mini HR crimp connectors, qty. 50
BNC male RG6 crimp connectors, qty. 50
BNC bulkhead connectors, qty. 50 (for custom wall plates)

Pre-cut cables

MHR-5 cable is used for RGBHV cable runs. It can also be used for composite
video, S-video, or RGsB. All Extron BNC cables have male connectors on both
ends. A plenum version of the MHR cable is also available.
MHR-5 Cable
MHR-5 BNC (6' /1.8 meters to 300' /90.0 meters)

Button Labels

Eight sets of button labels are provided on the next page. If desired, cut them out
of the manual, write the applicable button information in each button area, and
place them in the switcher's label window.
Integration Scaling Matrix Switcher • Reference Information
Bulk cable in lengths up to 5000' (1524 meter) rolls is available with or
without connectors.
Part #
22-098-02
22-098-03
22-100-02
22-020-02
22-020-03
22-103-02
22-103-03
100-250-01
100-260-01
100-076-51
26-260-xx
B-5
