Command/response table for SIS commands (cont'd)
Command
Resets
Zap all audio adjustments
Zap all ISM settings
Absolute reset

Command/response table for IP SIS commands

= ISM name
X30
= GMT Time and date (set)
X31
= Time and date (read)
X32
= IP address
X33
= Password
X34
= Hardware address
X35
= Number of open connections 0 - 255
X36
ASCII Command Response
(host to switcher) (switcher to host)
zA ZapA
Esc
zXXX Zapx
Esc
ZQQQ Zpq
Esc
(Up to 12 characters)
MM/DD/YY-HH:MM:SS, where
MM = month: 01 (January) through 12 (December)
DD = day: 01 through 31
YY = year: 00 through 99
HH = hour: 00 through 23
MM = minutes: 00 through 59
SS = seconds: 00 through 59
In the format: Day,•DD•MMM•YYYY•HH:MM:SS GMT, where
Day = weekday: Mon through Sun
DD = day: 01 through 31
MM = month: Jan through Dec
YYYY = year: 2000 through 2099
HH = hour: 00 through 23
MM = minutes: 00 through 59
SS = seconds: 00 through 59
###.###.###.###
12 alphanumeric characters
##-##-##-##-##-##
Integration Scaling Matrix Switcher • Programmer's Guide
Additional description
Reset all audio levels to 0dB.
Reset all settings:
All inputs: RGB
Ouput: RGBHV 1024x768 @ 60Hz
RGB delay: 0.0 sec. (both outputs)
Audio level: 0dB
Filtering: Horz. = 3, Vert. = 7
Blanking: 0, top and bottom
Pixel phase: 16
Auto Image: Off
Auto Memory recall: On
Similar to Zap all ISM settings,
plus clears IP address to
192.168.254.254 and deletes user
and adminstrator passwords.
4-13
