Fibre Alliance MIB Object Types

Overview

The object types in FCMGMT-MIB are organized into the following groupings:
•
Connectivity
•
Trap Registration
•
Revision Number
•
Statistic Set
•
Service Set

FCMGMT-MIB File System Organization

The following graphics depict the organization and structure of FA-MIB:
Figure 2-1
2-2
FA-MIB Overall Tree Structure
See Figure 2-2 on page 2-3
See Figure 2-3 on page 2-4
See Figure 2-3 on page 2-4
See Figure 2-3 on page 2-4
See Figure 2-4 on page 2-5
MIB Reference Manual Version 3.0
