FCSwitch MIB Object Types
swSensorStatus [swSensorTable]
Syntax
Value
Integer
Access Read-only
Status Mandatory
Description The current status of the sensor.
Note:
swSensorValue [swSensorTable]
Syntax
Integer
Access
Read-only
Status
Mandatory
Description
The current value (reading) of the sensor.
The value, -2147483648, represents an unknown quantity.
It also means that the sensor does not have the capability to measure the actual value. In V2.0, the
temperature sensor value will be in Celsius; the fan value will be in RPM (revolution per minute);
and the power supply sensor reading will be unknown.
Note:
4-22
Declaration
1 (unknown)
2 (faulty)
3 (below-min)
4 (nominal)
5 (above-max)
6 (absent)
See the following list for valid values:
•
For Temperature, valid values include 3 (below-min), 4 (above-max), and 4
(nominal).
•
For Fan, valid values include 3 (below-min), 4 (nominal)., and 6 (absent).
•
For Power Supply, valid values include 2 (faulty), 4 (nominal), and 6 (absent).
For Fan, the value -2147483648, indicates that the unit is missing.
For Power Supply, the return value is always -2147483648.
Description
The status of the sensor is unknown.
The status of the sensor is in a faulty state.
The sensor value is below the minimal threshold.
The status of the sensor is in a nominal state.
The sensor value is above the maximum threshold.
The sensor is missing.
