Note:
connUnitPortName [connUnitPortTable]
Syntax
Display String
Access
Read-write
Status
Mandatory
Description
A string describing the addressed port.
Note:
connUnitPortPhysicalNumber [connUnitPortTable]
Syntax Integer
Access
Read-only
Status
Mandatory
Description
This is the internal port number this port is known by. In many implementations, this should be the
same as connUnitPortIndex. Some implementations may have an internal port representation not
compatible with the rules for table indices. In that case, provide the internal representation of this
port in this object. This value may also be used in the connUnitLinkPortNumberX or
connUnitLinkPortNumberY objects of the connUnitLinkTable.
Note:
MIB Reference Manual Version 3.0
Return values are as follows:
resetConnUnitPort - portDisable (F or E_port, loop for U_port)
bypassConnUnitPort - portDisable (FL_port)
unbypassConnUnitPort - portEnable (FL_port)
offlineConnUnitPort - portDisable (E, F, FL_port)
onlineConnUnitPort - portEnable (U)
resetConnUnitPortCounters - clear the port stats counter. When rebooted, this defaults to 1
(unknown)
For an external FC port, this enables the port for the embedded port, thus enabling the
switch.
Each implementation may chose not to allow any or all of the following values on a SET.
If the Management Station uses in-band communication (FC-IP) with the switch, either of
the two following action may not be possible in-band:
•
Enabling the FC port that is connected to the Management Station,
•
Enabling the embedded port.
This returns Null and is read-only.
The internal port numbers for the FC Entry Switch 8B and FC Switch 8B: 0 through 7
The internal port numbers for the FC 16B: 0 through 15
Fibre Alliance MIB Object Types
2
2-41
