4 Configuration
Example
(Vty-0) #show uplink-set
Uplink External
Set Name ports
-------- -------------- ------------ ------------ ----- ------ ----- ----
default -
1_NET 0/11
1_NW1 0/12,0/13,0/14 0/13,0/14
1_NW2 0/15,0/16
(Vty-0
(Vty-0) #show port-group
Port Group Name
-------------------
default
1_INTERN_1
1_INTERN_2
1_NET
1_NW1
1_NW2
In the above example, the first uplink port 0/11 belongs to the uplink set 1_
NET, and the port group 1_NET is assigned to this uplink set.
If port 0/11 does not belong to any uplink set, but should belong to uplink set
1_NET, then enter the following commands:
(Vty-0) #configure
(Vty-0) (Config)#interface 0/11
(Vty-0) (Interface 0/11)#uplink-set 1_NET
(Vty-0) (Interface 0/11)# exit
(Vty-0) (Config)#exit
(Vty-0) #
If the first uplink port 0/11 belongs to the uplink set 1_NET, but no port group
108
External
active ports
-
0/11
0/15
Internal Ports
--------------
- default
-
-
0/1,0/2 1_NET
-
- 1_NW2
External Link
backup ports state Backup snoop LACP
- yes no
- yes yes
0/12 yes yes
0/16 yes
Uplink Set Name
-------------------
1_NW1
ServerView Virtual-IO Manager
Port IGMP
yes no
yes no
yes no
yes yes no
External Ports
--------------
-
-
-
0/11
0/12,0/13,0/14
0/15,0/16
