5.2

Tree view

The tree view is on the left of the work area in the Virtual-IO Manager and pro-
vides various views.
ServerView Virtual-IO Manager
Display on the right
on the left
Five tabs are displayed in the area on the right (see
"Tabs" on page
All Server Only the Virtual-IO Manager tab is activated, which
server group contains general information on VIOM.
VIOM Man- Same as if all servers of the group were selected.
ageable or
VIOM Man-
aged server
group
Object(s) in Only the Virtual-IO Manager and Setup tabs are acti-
the VIOM vated in the area on the right. You can activate VIOM
Manageable management of objects on the Setup tab.
server group
Object(s) in The Virtual-IO Manager, Setup, and Server Con-
the VIOM figuration tabs are activated in the area on the right.
Managed The Ext. LAN Connections and Chassis Con-
server group figuration tabs are only enabled if a single blade
server is selected.
An overview of the previously defined profiles
group
A profile Only the corresponding profile
It is not possible to select unmanaged and managed servers in the
server list at the same time.
142).
5.2 Tree view
139
