Installing The Virtual-Io Manager Using A Graphical Interface - Fujitsu ServerView Virtual-IO Manager V3.1 User Manual

3 Installation and uninstallation
3.4.1 Installing the Virtual-IO Manager using a graphical inter-
face
If you want to use the graphical installation, an X Windows server should be
installed on your desktop computer. Check the prerequisites for the VIOM
installation (see section
Installation process
1. Set the DISPLAY environment variable:
export DISPLAY=<IP-address|host name>:0.0
Example
2. If you prefer to have a dedicated directory for each VIOM package,
create one (e.g. /root/VIOM_3.1.0) and copy the zip file (e.g. VIOM_
3.1.0.2012.08.15.zip) from the installation medium to that directory and
unzip it:
mkdir /root/VIOM_3.1.0
cp VIOM_3.1.0.2012.08.15.zip /root/VIOM_3.1.0
cd /root/VIOM_3.1.0
unzip VIOM_3.1.0.2012.08.15.zip
74
"Prerequisites for the VIOM installation" on page
export DISPLAY=111.22.33.115:0.0
ServerView Virtual-IO Manager
57).
