5 Virtual-IO Manager user interface
Fabric 3
All paths are routed to fabric 3.
Fabric 4
All paths are routed to fabric 4.
Fabric 3 & 4
LAN1 is routed to fabric 3 and LAN2 to fabric 4.
For more information on SMUX settings, see the documentation "PRIM-
ERGY BX900 Blade Server Systems - ServerView Management Blade
S1".
The upper table displays the onboard ports (up to 6). Another table is dis-
played for each available mezzanine/PCI card configured in the previous
step. The tables have the following columns:
Column Significance
first col-
Port number of the onboard or the mezzanine/PCI card port. On
umn
CNA cards the type of the function (LAN, FCoE, iSCSI) can be
selected from the drop-down list.
Another function can be added to this port with the
Functions can be removed with the
210
button.
ServerView Virtual-IO Manager
button.
