Port Name
WWPN (worldwide port name) of the port for the boot device.
LUN
LUN (logical unit number) address of the boot device. The default value
for the field is 0.
2nd Target
In 2nd Target, you configure the backup boot device (optional).
Port Name
WWPN (worldwide port name) of the port for the backup boot device.
LUN
LUN (logical unit number) address of the backup boot device. The
default value for the field is 0.
Speed
Transmission speed used by the selected port. By default, auto nego-
tiate is selected. If auto negotiation is not selected on the external
switch, you configure the value using the drop-down menu according to
the settings on the external switch. The following values are available:
auto negotiate
Default
The transmission speed is negotiated with the external switch.
1Gbit/s
1 Gbit/s full-duplex
2 Gbit/s
2 Gbit/s full-duplex
4 Gbit/s
4 Gbit/s full-duplex
