5 Virtual-IO Manager user interface
Fault State
l
State Causes
l
The (Causes or State Causes) state cause is not at all a fault. It is simply a
state marker. The following values are defined:
Cause
data base doesn't match
hardware
not supported
model does not match
slot configuration
slot is empty
profile assigned
no configuration
no ServerView entry
different switches in fab-
ric
inapplicable profile
assigned
stacking error
Depending on what you select, the following buttons are available, that allow
you to carry out various actions.
Manage
Activates the management of the selected servers. The Authentication
dialog box opens. In this dialog box, you enter the user names and
146
Significance
Configuration of switch/server does not match
with database.
Switch/server model is not supported.
The model is supported, but some other require-
ments are not met.
No hardware plugged, although a configuration
exists.
Switch/server is used by an assigned server pro-
file.
No configuration of switch/server is stored
inside the database.
No entry of blade server inside of ServerView
Operations Manager.
The switch is incompatible with another switch
in the same fabric.
The assigned server profile is incompatible with
the plugged blade server.
The switch configuration is not compatible with
the stacking groups.
