7 Managing servers with VIOM
7.5 VIOM-internal operations on a PRIMERGY rack
server
This section explains the internal operations perfomed when you activate or
deactivate management with VIOM for a PRIMERGY rack server.
VIOM-internal operations during activation
When you activate management with the Virtual-IO Manager for a PRIM-
ERGY rack server, the following actions occur internally:
1. The PRIMERGY rack server is indicated as "managed" by this VIOM
installation. This is done by assigning a corresponding status to this
server node in the VIOM database and also by storing information about
the VIOM installation in a VIOM-specific property in the iRMC. This infor-
mation uniquely identifies the current VIOM installation. (Note: This infor-
mation is not changed during an update installation of VIOM, but it does
change when uninstalling and during a new installation.)
VIOM also changes a special VIOM-enabled flag in the iRMC from "not
enabled" to "enabled" and a trap destination is stored in the iRMC. The
trap destination is one of the required details that VIOM needs to manage
a PRIMERGY rack server. The trap destination must be the IP address
or server name of the ServerView management station where this Vir-
tual-IO Manager and ServerView Operations Manager are installed.
When you specify a server name, the iRMC must be able to resolve this
server name into a valid IP address via DNS so that SNMP traps sent by
iRMC to the IP address reach the VIOM management station.
266
This information in the iRMC is always checked before a server
is managed. If VIOM can recognize from this that a PRIM-
ERGY rack server is already managed by another Virtual-IO
Manager, you receive a corresponding warning. If, however,
you are sure that a server is no longer managed by another
VIOM installation, you can still add the server to the man-
agement despite the warning.
