1 Introduction
PCI controller
Emulex 10GbE OCe10102
CNA
Emulex 8Gb FC HBA
LPe 12002
Emulex 8Gb FC HBA LPe
1250 (1 channel)
INTEL 2-port 10GbE
(D2755 – Niantec)
INTEL 4-port (D2745 - Bar-
ton Hills)
INTEL 2-port (D2735 -
Kawela 82576NS)
INTEL Eth Ctrl 4x1Gb Cu
PCIe x4 (D3045)
INTEL Eth Ctrl 2x1Gb Cu
PCIe x4 (D3035)
INTEL 10GbE 10GBase-
T(RJ45) PCIe LAN
20
Scope of functions
Define physical functions and type (LAN,
FCoE, iSCSI) of physical functions.
Assign virtual addresses to physical function
and optionally define boot parameter.
This CNA supports two physical functions for
each of both physical ports. The first physical
function must be of type LAN. The physical
functions for the two physical ports must be
defined similarly. This means that the storage
function for both physical ports must be of the
same type. When using iSCSI with iSCSI boot
the iSCSI initiator must be identical. Excep-
tion: physical port is completely disabled.
Assign virtual WWPN and WWNN.
Optionally define the first and second boot tar-
get and LUN.
Disable I/O ports.
Assign virtual MAC.
Optionally define PXE boot per port.
Disable I/O ports.
There is no explicit disable
functionality for I/O ports in
VIOM. I/O ports that are not
defined in a VIOM profile will
be implicitly disabled if the
device supports this func-
tionality.
