2 Virtual-IO Manager - Introduction
In the case of IBP 30/12, the first 8 uplink ports are combined in one
uplink set by default, and all 30 downlinks are connected with this
standard uplink set.
Using VIOM, you can change the standard configuration of an IBP module.
You can combine several uplink ports into one uplink set as well as define
several uplink sets for a LAN connection blade. This gives you several inde-
pendent network paths e. g. for different applications (e. g. database server,
communication server) or individual areas (e. g. development, accounting or
personnel administration).
To find out what happens when you activate the management of a
blade server using the Virtual-IO Manager with the standard IBP con-
figuration, see
on page 261
The following figure provides an overview of typical uplink sets that you can
configure using VIOM.
32
section"VIOM internal operations on blade servers"
.
