SLM-5650 Satellite Modem
Installation
2.4

AC Power Connector

A standard, detachable, non-locking, 3-prong power cord (IEC plug) supplies the Alternating
Current (AC) power to the modem. Observe the following:
2.5

Ground Connector (GND)

A #10-32 stud on the rear panel of the modem is used for connecting a common chassis ground
among all equipment.
Note: The AC power connector provides the safety ground.
2.6

Gigabit Ethernet

The Gigabit Ethernet interface (AS/11985) supports 10/100/1000 BaseT operation. The LAN
interface is comprised of one IEEE 802.3ab 1000Base-T copper interface via a single female RJ-
45 connector (J1).
Input Power 65W maximum, 50W typical
Input Voltage 90 to 132 or 175 to 264 VAC
Unit switches ranges automatically
Connector I.E.C
Type
Fuse 1A slo-blo
Protection
Line and neutral fusing
5 mm type fuses
Pin # Description
1 BI_DA+
2 BI_DA-
3 BI_DB+
4 BI_DC+
5 BI_DC-
6 BI_DB-
7 BI_DD+
8 BI_DD-
Direction
bidirectional
bidirectional
bidirectional
bidirectional
bidirectional
bidirectional
bidirectional
bidirectional
2–11
Revision 2
MN/SLM5650.IOM
