Comtech EF Data SLM-5650 Installation And Operation Manual page 54

SLM-5650 Satellite Modem
Configuration
Modulation
Type
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 3/4
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
Overhead R-S Code
Word
IESS-308 194,178
IESS-308 194,178
IESS-308 194,178
IESS-308 194,178
IESS-308 194,178
IESS-308 219,201
IESS-308 219,201
IESS-308 219,201
IESS-308 219,201
IESS-308 219,201
IESS-308 219,201
IESS-308 225,205
IESS-308 225,205
IESS-308 225,205
IESS-308 225,205
IESS-308 225,205
IESS-308 225,205
IESS-308 126,112
IESS-308 126,112
IESS-308 126,112
IESS-308 126,112
IESS-308 126,112
IESS-308 126,112
IESS-308 208,192
IESS-308 208,192
IESS-308 208,192
IESS-308 208,192
IESS-308 208,192
IESS-308 208,192
IESS-308 Off
IESS-308 Off
IESS-308 Off
IESS-308 Off
IESS-308 Off
IESS-308 Off
IESS-308 Off
IESS-308 194,178
IESS-308 194,178
IESS-308 194,178
IESS-308 194,178
IESS-308 194,178
IESS-308 194,178
IESS-308 194,178
IESS-308 219,201
IESS-308 219,201
IESS-308 219,201
IESS-308 219,201
IESS-308 219,201
IESS-308 219,201
IESS-308 219,201
IESS-308 225,205
IESS-308 225,205
3–4
R-S Depth Data Rate
(kbps)
4, 8, 16 2048 1584.06
4, 8, 16 6312 4682.247
4, 8, 16 8448 6324.247
4, 8, 16 32064 23393.438
4, 8, 16 34368 25067.506
4, 8, 16 1544 1217.512
4, 8, 16 2048 1583.602
4, 8, 16 6312 4680.836
4, 8, 16 8448 6232.358
4, 8, 16 32064 23386.269
4, 8, 16 34368 25059.821
4, 8, 16 1544 1225.756
4, 8, 16 2048 1594.537
4, 8, 16 6312 4714.537
4, 8, 16 8448 6277.463
4, 8, 16 32064 23557.463
4, 8, 16 34368 25243.317
4, 8, 16 1544 1254
4, 8, 16 2048 1632
4, 8, 16 6312 4830
4, 8, 16 8448 6432
4, 8, 16 32064 24144
4, 8, 16 34368 25872
4, 8, 16 1544 1216.472
4, 8, 16 2048 1582.222
4, 8, 16 6312 4676.583
4, 8, 16 8448 626.667
4, 8, 16 32064 23364.667
4, 8, 16 34368 25036.667
N/A 1544 882.286
N/A 2048 1170.286
N/A 6312 3606.857
N/A 8448 4827.428
N/A 32064 20040.571
N/A 34368 21473.714
N/A 44736 27922.857
4, 8, 16 1544 1057.592
4, 8, 16 2048 1371.48
4, 8, 16 6312 4027.069
4, 8, 16 8448 5357.355
4, 8, 16 32064 20065.233
4, 8, 16 34368 21500.148
4, 8, 16 44736 27957.265
4, 8, 16 1544 1057.296
4, 8, 16 2048 1371.087
4, 8, 16 6312 4025.859
4, 8, 16 8448 5355.736
4, 8, 16 32064 20059.087
4, 8, 16 34368 21493.561
4, 8, 16 44736 27948.691
4, 8, 16 1544 1064.362
4, 8, 16 2048 1380.46
Revision 2
MN/SLM5650.IOM
Symbol Rate
(ksps)
