SLM-5650 Satellite Modem
Remote Control
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
IP Address IPA= 18 bytes,
numerical
Carrier Only COM= 1 byte, value
Test Modes of 0 thru 2
Loopback LOP= 1 byte, value
Test Modes of 0 thru 3
Tx BERT BTX= 1 byte, value
State of 0 or 1
Rx BERT BRX= 1 byte, value
State of 0 or 1
Description of Arguments
to Query
Command or Query.
Used to set the IP address and network prefix for the
10/100 BaseTx Ethernet management port, in the format:
xxx.xxx.xxx.xxx.yy, where:
xxx.xxx.xxx.xxx is the IP address, and
yy is the network prefix (0-31)
Example: 010.006.030.001.24
Command or Query.
Test Mode, where:
0= Normal Mode (no test)
1=Tx CW
2=Tx Alternating 1,0 Pattern
Example: COM=1 (CW Mode)
Command or Query.
Loopback Test Modes, where:
0=Normal Mode (no test)
1=IF Loopback
2=I/O Loopback #1
3=I/O Loopback #2
Example: LOP=1 (IF Loopback)
Command or Query.
Tx BERT State, where:
0=Off
1=On
Example: BTX=1 (Tx BERT On)
Command or Query.
Rx BERT State, where:
0=Off
1=On
Example: BRX=1 (Rx BERT On)
Response to
Command
IPA=
IPA?
IPA*
IPA#
COM=
COM?
COM*
COM#
LOP=
LOP?
LOP*
LOP#
BTX=
BTX?
BTX*
BTX#
BRX=
BRX?
BRX*
BRX#
B–20
Revision 1
MN/SLM5650.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
IPA? IPA= xx.xxx.xxx.xxx.yy
(see description of
arguments)
COM? COM=x
(see description of
arguments)
LOP? LOP=x
(see description of
arguments)
BTX? BTX=x
(see description of
arguments)
BRX? BRX=x
(see description of
arguments)
