Comtech EF Data SLM-5650 Installation And Operation Manual page 151

SLM-5650 Satellite Modem
Remote Control
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
Modem Alarm MSK= 6 bytes
Mask
Statistics SSI= 1 byte
Sample
Interval
Number of N/A 3 bytes
Unread stored
Statistics
Initialize ISP= None
Statistics
Pointer
Description of Arguments
to Query
Command or Query.
Alarm mask conditions, in the form abcdef, where:
a=spare ( must be set to 0 )
b=spare ( must be set to 0 )
c=spare ( must be set to 0 )
d=spare ( must be set to 0 )
e=spare ( must be set to 0 )
f=Eb/No Threshold Alarm ( 0 = unmasked, 1 = masked )
Example: MSK=000001
Command or Query.
Used to set the sample interval for the Statistics Logging Function.
SSI=x, where x = 0 to 9 in 10 minute steps.
Note: Setting this parameter to 0 disables the statistics logging
function.
Example: SSI=3 sets the logging inverval to 30 minutes
Query only.
Unit returns the Number of stored Statistics, which remain Unread,
in the form xxx.
Note: This means unread over the remote control.
Example: NUS=126
Command only.
Resets internal pointer to allow RNS? queries to start at the
beginning of the stored statistics log.
Response to
Command
MSK=
MSK?
MSK*
MSK#
SSI=
SSI?
SSI*
SSI#
N/A
ISP=
ISP#
B–29
Revision 1
MN/SLM5650.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
MSK? MSK=abcdef
(see description of
arguments)
SSI? SSI=x
(see description of
arguments)
NUS? NUS=xxx
(see description of
arguments)
N/A N/A
