2.3.5 EIA-530 Connector, (J6)

The Data connector is a 25-pin 'D' type female (DB25-F). This connector conforms to the EIA-
530 pin-out for EIA-422 operation only.
Pin # Name
1 Ground
14 SD_B
2 SD_A
15 ST_A
3 RD_A
16 RD_B
4 RS_A
17 RT_A
5 CS_A
18 MOD FLT OC
6 DM_A
19 RS_B
7 Ground
20 Not Used
8 RR_A
21 DMD FLT OC
9 RT_B
22 DM_B
10 RR_B
23 Not Used
11 TT_B
24 TT_A
12 ST_B
25 Not Used
13 CS_B
