CDM-600 Satellite Modem
Connector Pinouts
5.11
AC Power Connector
A standard, detachable, non-locking, 3-prong power cord (IEC plug) supplies the
Alternating Current (AC) power to the modem. Note the following:
AC Power Specifications
Input Power
Input Voltage
Connector Type
Fuse Protection
5.12
Ground Connector
A #10-32 stud on the rear panel of the modem is used for connecting a common chassis
ground among equipment.
Note: The AC power connector provides the safety ground.
40W maximum, 30W typical
100 - 240 volts AC, +6%/-10% - autosensing
(total absolute max. range is 90 - 254 volts AC)
IEC
1.25A Slow-blow (115 volt AC operation)
0.75A Slow-blow (230 volt AC operation)
Line and neutral fusing
20 mm type fuses
5–7
Revision 7
MN/CDM600.IOM
