SLM-5650 Satellite Modem
Remote Control
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
Global MGC= 177 bytes, with
Configuration numerical
entries, fixed
values and
delimiters
Description of Arguments
to Query
Command or Query.
Global Configuration of SLM-5650, in the form:
abcdeeeeeefghijkkkkkkkklmnoooooo.ooopppp.ppppqrrrstuvwxyyy.
yzABCDEFGHHHHHHHHIJKLLLLLL.LLLMMMM.MMMMN
OOOPQRSTUVWXYZZZZ.ZZZAAABCDDDDDDDDEE.EFGH
IJKLMNNN.NOOO.OPPP.PQQ.QR.RSTUUUUUUUU where:
a = Modem Operating Mode
b = Modem RF Band
c = Modem Interface Type
d = Modem Reference Clock
eeeeee = Modem Alarm Mask
f = Carrier Only Test Modes
g = Loopback Test Modes
h = Tx BERT State
i = Rx BERT State
j = BERT Pattern
kkkkkkkk = expansion bytes
l = Tx FEC Type
m = Tx Modulation Type
n = Tx Code Rate
oooooo.ooo = Tx Data Rate
pppp.pppp = Tx Frequency
q = Tx Overhead Type
rrr = Reserved
s = Tx Reed-Solomon state
t = Tx Reed-Solomon code word
u = Tx Reed-Solomon interleaver depth
v = Tx Spectrum Invert
w = Tx Scrambler
x = Tx Differential Encoder
yyy.y = Tx Power Level
z = Tx Clock Source
Response to
Command
MGC=
MGC?
MGC*
MGC#
same as MOM
same as RFB
same as ITF
same as MRC
same as MSK
same as COM
same as LOP
same as BTX
same as BRX
same as PAT
same as TFT
same as TMD
same as TCR
same as TDR
same as TFQ
same as TFM
same as TRS
same as TCW
same as TRD
same as TSI
same as TSC
same as TDE
same as TPL
same as TCK
B–36
Revision 1
MN/SLM5650.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
MGC? MGC=abcdeeeeeefghijk
kkkkkkklmnoooooo.ooo
pppp.ppppqrrrstuvwxyy
y.yzABCDEFGHHHHH
HHHIJKLLLLLL.LLL
MMMM.MMMMNOO
OPQRSTUVWXYZZZZ
.ZZZAAABCDDDDDD
DDEE.EFGHIJKLMNN
N.NOOO.OPPP.PQQ.Q
R.RSTUUUUUUUU
(see description of
arguments)
